Overview
PE series jaw crushers are used as primary crushers in aggregate production, mining and recycling. As the most classic design, it is one of the most durable crusher in history, widely used all over the world. The PE series jaw crushers have proven to be stable and reliable due to their long history and countless cases. Continuous improvement and development has resulted in several models to suit a variety of different situations and requirements. The simple structure allows for easy maintenance and stable use by users, minimizing the risk of accidental failure.
Key Features
Reliable equipment operation
Greater fatigue resistance, higher reliability, and longer service life provide a good operating environment for the equipment.
High output and crushing ratio
The crushing ratio is large and the operation is stable, which fully guarantees the high output and high efficiency of the crushing operation.
Easy maintenance
The operation is simple and the adjustment is quick, which reduces the maintenance cost and labor cost of the equipment.
The adjustment of the discharge opening is quicker and more convenient
Discharge port gasket adjustment, simple, reliable and easy to maintain.
Working Principle
The motor drives the belt and pulley, and the movable jaw moves up and down through the eccentric shaft. When the movable jaw rises, the angle between the toggle plate and the movable jaw is When the movable jaw goes down, the angle between the toggle plate and the movable jaw becomes smaller, and the movable jaw is on the tie rod. Under the action of the spring, it leaves the fixed jaw plate. At this time, the crushed material is discharged from the lower opening of the crushing cavity. With the continuous rotation of the motor, the crushing jaws do periodic motion to crush and discharge materials to achieve mass production.
